In stock
€91.50
Tax included

OMNIKEY® 5513 reader HF Mifare Easy

The MIFARE Easy reader board family is a practical and cost-effective solution for system integrators and terminal manufacturers who are looking for a secure and scalable option for use in cashless payment applications. The MIFARE-Easy reader boards with read / write function can be easily integrated into compact terminals or mobile units. This makes them ideal for use in direct debit (AFC), ticket machines, validators, card printers, mobile solutions and various other devices for cashless payment transactions.

This product is custom made.



Specification:

ELECTRICAL
RFID family HF
Operating Frequency 13,56 MHz
Supported TAGs MIFARE Standard / 4k / Pro X / Ultralight / DESFire
Supported Standards ISO 14443 A
NFC compliant yes
Internal antenna 1
External antenna ports -
Max. RFID transmit power -
RS232 / USB / LAN / WLAN / Bluetooth / TTL yes / no / no / no / no / no
Digital I/O's 2 status indicator LED lines
Power sources 5.0 VDC @ 150 mA
Power over ethernet (PoE) no

MECHANICAL
Material -
Colour -
Dimensions 70 x 45 x 12,1 mm / 2.76 x 1.77 x 0.48 in
Weight 16 g / 0.56 oz
Mounting capabilities -

ENVIRONMENTAL RESISTANCE
Operating temperature -20° to +80° C / -4° to +176° F
Storage temperature -40° to +85° C / -40° to +185° F
IP classification -

SOFTWARE
Operating system -
On-board web interface -
Standard IP address -
RFID operation interfaces -
Embedded applications possible -
0701800029-IDT
