Single or Dual-sided Printing
Dual-sided
Single-sided
Color Capability
Full Color
Monochrome
Print Method
Direct-to-Card Dye Sublimation
Lamination
None
Card Feeder
Integrated Card Feeder
Card Feeder/Hopper Capacity
Card feeder capacity: 100 cards (30 mil)
Card output capacity: 45 cards (30 mil)
Memory
16 MB image memory (standard)
Print speed
40 seconds/card (full color, dual sided)
MEDIA CHARACTERISTICS
Ribbons
Zebra True Colours iSeries intelligent technology media
Zebra True Colours iSeries Load-N-Go drop-in ribbon cartridge with integrated card cleaning roller
YMCKO ribbon: 200 images/cartridge
YMCKOK ribbon: 165 images/cartridge
Monochrome ribbon: 1000 images/cartridge
OPERATING CHARACTERISTICS
Operating temperature
60° F (15° C) to 86° F (30° C)
Storage temperatures
23° F (-5° C) to 158° F (70° C)
Operating humidity
20% to 65% non-condensing
Storage humidity
20% to 70% non-condensing
Electrical
100 - 240 Volts AC, 50 - 60 Hz (auto switching)
Ventilation: Free air
Agency approvals
FCC Class A, CE, UL, CUL approved
PHYSICAL CHARACTERISTICS
Width
7.9" (201 mm)
Height
9.25" (235 mm)
Depth
12.9" (328 mm)
Weight
10 lbs (4.5 kg)
RELATED PRODUCTS
Card Encoding Options
Magnetic encoder 3 track HiCo/LoCo (30 mil cards only)
Options
CardSense single-card feed mode
Built-in 10/100 Ethernet
Starter kit: 200 - 30 mil PVC cards and 1 YMCKOK ribbon
Cleaning kit: 4 print engine and 4 feeder cleaning cards
Extended warranty program
Hot swap warranty programs (USA only)
Communication and Interface Capabilities
USB 1.1 (USB 2.0 compatible) cable included (standard)
Built-in 10/100 Ethernet (optional)
BAR CODES/SYMBOLOGIES
Linear
Code 39
Interleaved 2-of-5
UPC-A
2-D PDF 417
EAN-8 and EAN-13
Other Symbologies via Windows Driver
CARD DETAIL
Card Types
PVC, PVC Composite
Magnetic stripe ISO 7811
Card Size
CR-80 ISO 7810, 2.12" (54 mm) x 3.38" (86 mm)
Card Thickness
30 mil 30 mil
Single or Dual-sided Printing
Color Capability
Print Method
- Direct-to-Card Dye Sublimation
Lamination
Card Feeder
- Integrated Card Feeder
- Card Feeder/Hopper Capacity
- Card feeder capacity: 100 cards (30 mil)
- Card output capacity: 45 cards (30 mil)
Memory
- 16 MB image memory (standard)
Print speed
- 40 seconds/card (full color, dual sided)
MEDIA CHARACTERISTICS
Ribbons
- Zebra True Colours iSeries intelligent technology media
- Zebra True Colours iSeries Load-N-Go drop-in ribbon cartridge with integrated card cleaning roller
- YMCKO ribbon: 200 images/cartridge
- YMCKOK ribbon: 165 images/cartridge
- Monochrome ribbon: 1000 images/cartridge
OPERATING CHARACTERISTICS
Operating temperature
- 60° F (15° C) to 86° F (30° C)
Storage temperatures
- 23° F (-5° C) to 158° F (70° C)
Operating humidity
- 20% to 65% non-condensing
Storage humidity
- 20% to 70% non-condensing
Electrical
- 100 - 240 Volts AC, 50 - 60 Hz (auto switching)
- Ventilation: Free air
- Agency approvals
- FCC Class A, CE, UL, CUL approved
PHYSICAL CHARACTERISTICS
Width
Height
Depth
Weight
RELATED PRODUCTS
Card Encoding Options
- Magnetic encoder 3 track HiCo/LoCo (30 mil cards only)
Options
- CardSense single-card feed mode
- Built-in 10/100 Ethernet
- Starter kit: 200 - 30 mil PVC cards and 1 YMCKOK ribbon
- Cleaning kit: 4 print engine and 4 feeder cleaning cards
Extended warranty program
- Hot swap warranty programs (USA only)
Communication and Interface Capabilities
- USB 1.1 (USB 2.0 compatible) cable included (standard)
- Built-in 10/100 Ethernet (optional)
BAR CODES/SYMBOLOGIES
- Linear
- Code 39
- Interleaved 2-of-5
- UPC-A
- 2-D PDF 417
- EAN-8 and EAN-13
- Other Symbologies via Windows Driver
CARD DETAIL
Card Types
- PVC, PVC Composite
- Magnetic stripe ISO 7811
Card Size
- CR-80 ISO 7810, 2.12" (54 mm) x 3.38" (86 mm)
Card Thickness
