OMNIKEY® 5553 Reader Board HF Multi ISO RS232

Name: OMNIKEY® 5553 Reader Board HF Multi ISO RS232
Brand: MCO Service
SKU: 0701800160
Price: 164.70 EUR
Availability: InStock

SKU:0701800160

€164,70 EUR

Sale Sold out

Taxes included.

OMNIKEY® 5553 Reader Board HF Multi ISO RS232

The Multi-ISO Reader Core provides contactless read / write capabilities and supports various ISO14443 A / B and ISO 15693 RFID devices. Reader Board offers a built in RS232 interface along with integrated antenna and SAM socket.

20 in stock

View full details

Description

Contactless HF reader board for Industry and logistics applications.

Specification:

ELECTRICAL
RFID family	HF
Operating Frequency	13,56 MHz
Supported TAGs	MIFARE™ Standard / EV1, MIFARE 4k / Plus / Pro / Ultralight / Ultralight C / DESFire EV1 /EV2,
Supported Standards	ISO14443A, ISO14443B, ISO 15693, ISO 18000-3, NFC enabled, ICODE
NFC compliant	yes
Internal antenna	1
External antenna ports	-
Max. RFID transmit power	-
RS232 / USB / LAN / WLAN / Bluetooth / TTL	yes / no / no / no / no / no
Digital I/O's	2 status indicator LED lines
Power sources	5.0 VDC @ < 150 mA
Power over ethernet (PoE)	no

MECHANICAL
Material	-
Colour	-
Dimensions	70 x 45 x 12,1 mm / 2.76 x 1.77 x 0.48 in
Weight	17 g / 0.6 oz
Mounting capabilities	-

ENVIRONMENTAL RESISTANCE
Operating temperature	-20° to +80° C / -4° to +176° F
Storage temperature	-40° to +85° C / -40° to +185° F
IP classification	-
